Three-Phase Smart Meter

DTZ1513

Direct-connection three-phase modular AMI meter — one metrology body with hot-swappable RF mesh or cellular communication.

View specifications Request quote
Product Overview

Three-phase modular AMI platform

The DTZ1513 is Delta Prima’s direct-connection three-phase smart meter for commercial and industrial services. Deploy RF mesh for neighbourhood AMI, or fit a cellular modem for direct remote management without a data concentrator.

Per-phase metrology, infrared and RS485 ports, DLMS/COSEM compliance, multi-tariff billing, and anti-tamper protection safeguard utility assets across C&I installations.

  • RF Mesh module

    Self-healing AMI network with extended coverage for dense C&I deployments and HHU field reading.

  • Anti-tamper protection

    Detection for magnetic interference, cover opening, and phase manipulation.

  • Multi-tariff billing

    Up to 8 tariffs with time-of-use, seasonal, and import/export pricing.

Class 1.0 / 2.0 Active energy accuracy
10(100) A Direct connection current
IP54 Ingress protection
Hot-swap RF or cellular module
Download RF brochure Download cellular brochure Request quote

Product brochures with technical data sheets (PDF) — RF mesh and cellular variants.

DTZ1513 three-phase RF smart meter — angled view

RF mesh · angled view

Communication Options

One meter body, two AMI paths

Select the communication module at order — swap later without changing the DTZ1513 metrology platform.

RF Mesh

C&I neighbourhood AMI

RF mesh connects meters in a self-healing network to a data concentrator. Ideal for commercial campuses, industrial parks, and mixed C&I rollouts with HHU field reading.

Cellular

Direct remote reading

GPRS/3G/4G/NB-IoT reports directly to the head-end system — no DCU required. Suited for remote C&I sites and high-value accounts.

Key Capabilities

Built for C&I three-phase AMI

Shared across RF and cellular DTZ1513 configurations.

Real-time event detection

Instant alerts for tampering, power outages, and critical events to enable rapid response.

Bi-directional metering

Measure import and export energy per phase for solar installations and distributed generation.

Remote load control

Built-in relay for remote connect/disconnect operations and demand response programs.

Multi-tariff & TOU

Up to 8 tariffs supporting time-of-use, seasonal, and import/export pricing strategies.

Advanced tamper detection

Magnetic interference, cover opening, reverse flow, and phase manipulation detection.

Power quality monitoring

Per-phase voltage, current, power factor, frequency, and harmonic distortion for grid insight.

Standards & compliance
  • IEC 62052-11
  • IEC 62053-22
  • IEC 62053-23
  • IEC 62055 series
  • IEC 62056 / DLMS
  • IEC 61000-4-2
  • IP54
Technical Data

Meter specification

Official DTZ1513 ratings — shared metrology with communication module specified at order.

Select communication module

DTZ1513 · RF Mesh

Model DTZ1513 · Three-phase AMI meter

Data sheet

Electrical & metrology

Reference voltage3×230/240/400/415 V AC (three-phase four-wire)
Operational voltage80%Un – 130%Un
Maximum switching voltage>415 V
Maximum withstand voltagePhase-to-Phase / Phase-to-Neutral: 4 kV, 50 Hz; Phase-to-Earth: 2 kV, 50 Hz
Current10(100) A
Frequency50 Hz / 60 Hz
Accuracy classActive Energy Class 1.0 / Class 2.0
Impulse constant1,000 imp/kWh
RelayBuilt in
Measurable quantitiesActive Power, Reactive Power, Apparent Power, Power Factor, Import/export Energy, Per-phase active/reactive power

Communication & interface

Communication interfaceBuilt-in RF mesh module; infrared and RS485 port
ProtocolDLMS/COSEM compliance
RF connectivityRF mesh module for remote management and reading

Display (LCD)

Energy registersActive energy (kWh), Reactive energy (kVARh), Apparent energy (kVAh), Import/export energy
Instantaneous valuesPer-phase voltages L1/L2/L3 (V), Per-phase currents L1/L2/L3 (A), Power factor (PF), Frequency (Hz), Per-phase active/reactive power
Status & diagnosticsTariff registers, Relay/load status, Alarms/fault codes

Tariff

Tariff capacityUp to 8 tariffs
Tariff typesTime of Use, Seasonal Tariffs, Import/Export Tariff

Environmental & protection

Operating temperature−25 °C to +70 °C
Ingress protectionIP54
Lightning protectionBuilt-in varistor
Maximum altitudeUp to 3,500 m
Fire retardant650 °C and 960 °C glow wire tests
Electrostatic discharge (ESD)Constant discharge ±8 kV; Air discharge 15 kV (IEC 61000-4-2)

Standards & compliance

General requirementsIEC 62052-11
Active energyIEC 62053-22, IEC 62053-23
Metering interfaceIEC 62055 series
Data exchangeIEC 62056-21; DLMS and COSEM interoperability
ESD immunityIEC 61000-4-2

For project-specific options and full type-test documentation, contact Delta Prima Metering.

Specify DTZ1513 for your C&I rollout

Our team can help match RF or cellular communication, tariff mode, and deployment topology to your utility standard and project plan.
